BARNES CENTRAL COOLANT SYSTEM

BARNES SUPER-VAC COOLANT SYSTEM PRICE: Loaded on Truck, Our Warehouse, York, PA … $99,500.00 HMC Stock # 23139-P Machine Serial No.: 2909 Machine Job No.: SV-2903 New Date: May 2013 CONCEPT: The filter was purchased for use with Gehring Hone for honing of cast iron cylinder blocks at major automotive powertrain facility. The fluid was straight oil, Castrol Honilo 980 High Performance Neat Oil Coolant (41.2 SSU) and the filter delivered 80 gallons per minute. EQUIPMENT: Control: SIEMENS Simatic S7-1200 (1214C PLC) with 6" Color Touch Screen Vacuum Filter: Barnes #SV-4-60 with 3/4 HP 1750 RPM 56C Motor and 951:1 LHYJ-3B14DBY3-Y1 Sumitomo Reducer Filter Pump: Grundfos CR32-3-2, 139 GPM@190' TDH, with 10 HP 3500 RPM Motor Magnetic Separator: Barnes MCS-1530 with 1/4 HP 1800 RPM 56C Motor (2) Bag Filters: Rosedale Duplex Vessel Unit # DHLP24-30-3F-1-150 C-B-N-PB with (6) Crystal Filtration Baskets, #BKROSEP2A02 and (6) Rosedale #PE-10G2RPE 10 Micron Bags for Each Vessel Heat Exchanger: Precise Cooling Solutions 10 Ton Heat Exchanger with 24 VDC Controls SPECIFICATIONS: Model: Barnes SUPER-VAC Size: SV-60 Machine Flow: 80 GPM Heat Exchanger Flow: 80 GPM Filter Internal Flow: 20 GPM Total Filter Flow: 100 GPM Filtration Area: 60 Sq/Ft Flux: 1.67 GPM/Sq Ft Septum: Perforated, Mild Steel Media: 51" Wide Sides: 3' High Discharge Height: 5' High Above Finished Floor Floor Dimensions: 23' 6" x 108" Approx. Chain: X456 Flights: 3/8" x 1-1/2" CRS Spacing: 8" Clean Tank Volume: 130 Gallons Index Valve Size: 3" INITIAL FILL CAPACITIES: Filter: 1254 Gallons Clean Tank: 178 Gallons System: 100 Gallons Total: 1532 Gallons EQUIPPED WITH: Inlet Velocity Reducer Dual Media Roll Holder Filter Tank Mist Collector Connection Filter Cleanout Door Conveyor Drive Overload Protection Bronze Ball Valves Efector #PN2209 Vacuum Switch Low Level Sensor in Clean Tank Media Sensor Coolant Header Pressure and Temperature Transducer Filter paper Catch Cart on Wheels Sludge Catch Cart on Wheels Unit was retired August 2023 because company was changing the facility from ICE Powertrain to EV Production. While this filter was originally supplied for a Gehring honing operation, it is suitable for other applications that require 80 GPM of oil coolant. The Barnes people are available for any further upgrades or alterations. Overall Size For Trucking: Main Unit: 382" (31.83') Long x 93" Wide x 136" High x 22,500 Lbs. Filter paper Catch Cart: 75" Long x 34" Wide x 28" High x 738Lbs. Sludge Catch Cart: 60" Long x 38" Wide x 44" High x 470 Lbs. TO SEE MORE INFORAMTION and DRAWINGS click on VIEW MORE INFORMATION (seen in red) below https://www.hildebrandmachinery.com/23139-moreinformation.pdf
