NARDINI GAP BED ENGINE LATHE

20" X 120" NARDINI GAP BED ENGINE LATHE PRICE: Loaded on Truck, Our Warehouse, York, PA …… $12,500.00 HMC Stock No. 18402 Machine Serial No. C1HH0SZ164 Machine Model No. SZ20120T New Date: Unknown Swing Over Bed: 20" Cross Slide Travel: 13 ¼" Distance Between Centers: 120" Carriage Travel: 115" Maximum Spindle Mount: D-8 Camlock Spindle Bore: 3.183" (18) Spindle Speeds: 19 to 1500 RPM (66) Longitudinal Feeds: .0021 to .0624" per Rev. (66) Cross Feeds: .001 to .0325 " per Rev. (54) Inch Threads: 2-3/4" to 42 TPI (54) Metric Threads: .40 to 18.472 mm Quill Diameter: 3-1/8" Quill Travel: 8" Quill Taper: #4 Morse EQUIPPED WITH: 12" 3-Jaw Chuck with Hard Reversible Top Jaws Taper Attachment Steady Rest Quick Change Tool Post Rear Splash Guard ? HP Main Motor, Wired for 3 Phase, 60 Cycle, 220 Volts Overall Size: 192" L-R x 50" F-B x 53" H x Approx. 10,000 Lbs.
