18407 1984 JET SECOND OPERATION LATHE TL-42

JET SECOND OPERATION LATHE PRICE: Loaded on Truck, Our Warehouse, York, PA …… $950.00 HMC Stock No. 18407-P Machine Serial No. 734919 Machine Model No. TL-42 New Date: November 1984 Mfg'd. by Lin Huan Machinery Co., Ltd., Taiwan Swing Over Bed: 11-3/4" (300 mm) Center Height: 5-7/8" (150 mm) Overall Length of Bed: 37-1/2" (954 mm) Spindle Bore Diameter: 2-1/16" (52 mm) Max. Chucking Diameter for Bar Work in Collet: 1-5/8" (42 mm) Max. Chucking Diameter for Bar Work in Jaw Chuck: 6" (150 mm) Spindle Speeds: 450, 810, 1250, 1800 RPM Nose Thread Metric, Dia. x Pitch: M 90 x 2 Cross Slide - Max. Travel: 6-5/16" (160 mm) Swing Over Slide: 8-1/4" (210 mm) Turret Slide - Max. Useful Stroke: 4-5/16" (110 mm) Max. Distance from Turret Face to Spindle Nose: 11-3/4" (300 mm) EQUIPPED WITH: NO Cross Slide Assembly 6-Sided Tool Turret with 1" Dia. Tool Pockets Turret has 6 Adjustable Stop Rods Built-In Chip Pan (1) 4" 6 Jaw Chuck with 1 Piece Hard OD and ID Chuck Jaws (1) 5" 3 Jaw Chuck with 1 Piece Hard Reversible Jaws Jet Tool Box and Owners Manual Spanner Wrench for Spindle Lever Type Collect Closure System Bed Turret is Adjustable on Length of Bed (1) Master Collect Designed for Use with Bolt in Collect Pads (#7219-Shoma-B-AL-AS) (1) 1" Diameter Collect Main Drive Motor: 3 HP (2.25 kw) Wired for 3 Phase, 60 Hz, 220 Volt Operation Overall Size: 60" L-R x 28" F-B x 53" High x 1,400 Lbs.
